Plastic Box Sections may be used for framing, cables, spacers and covers. These box shaped tube profiles are manufactured from PPH (Homopolymeric Polypropylene) that, in the group of polyolefins, has a very low density and a very high heat deflection temperature. PPH has a good rigidity and hardness, and is not prone to stress cracking. Its chemical resistance is very high, but the oxidation resistance is in the lower range.
Choose from a range of sizes to suit your design.
| Material | PPH |
| Shape | Rectangular Tube |
| Colour | Light Grey |
| Density (g/cm³) | 0.91 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 32 |
| Elongation at break (%) | ≥30 |
| Notched impact strength (kJ/m²) | 50 |
| Shore hardness (scale D) | 77 |
| Melting temperature (°C) | 160 |
| CLTE (10⁻⁶K⁻¹) | 150 |
| Service temp long term min (°C) | 5 |
| Service temp long term max (°C) | 100 | Heat deflection temperature (°C) | 96 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | >10¹³ |
| Surface resistivity (Ω) | >10¹³ |
| Material type | Extruded |
Minimum order value excluding VAT & delivery is £25
